MBRD620CTG Series, NRVBD640CTG Series
http://onsemi.com
6
PACKAGE DIMENSIONS
DPAK (SINGLE GAUGE)
CASE 369C
ISSUE D
b
D
E
b3
L3
L4
b2
e
0.005 (0.13)
M
C
c2
A
c
C
Z
DIM MIN MAX MIN MAX
MILLIMETERS
INCHES
D
0.235 0.245 5.97 6.22
E
0.250 0.265 6.35 6.73
A
0.086 0.094 2.18 2.38
b
0.025 0.035 0.63 0.89
c2
0.018 0.024 0.46 0.61
b2
0.030 0.045 0.76 1.14
c
0.018 0.024 0.46 0.61
e
0.090 BSC 2.29 BSC
b3
0.180 0.215 4.57 5.46
L4
???
0.040
???
1.01
L
0.055 0.070 1.40 1.78
L3
0.035 0.050 0.89 1.27
Z
0.155
???
3.93
???
NOTES:
1. DIMENSIONING AND TOLERANCING PER ASME
Y14.5M, 1994.
2. CONTROLLING DIMENSION: INCHES.
3. THERMAL PAD CONTOUR OPTIONAL WITHIN DI-
MENSIONS b3, L3 and Z.
4. DIMENSIONS D AND E DO NOT INCLUDE MOLD
FLASH, PROTRUSIONS, OR BURRS. MOLD
FLASH, PROTRUSIONS, OR GATE BURRS SHALL
NOT EXCEED 0.006 INCHES PER SIDE.
5. DIMENSIONS D AND E ARE DETERMINED AT THE
OUTERMOST EXTREMES OF THE PLASTIC BODY.
6. DATUMS A AND B ARE DETERMINED AT DATUM
PLANE H.
12 3
4
5.80
0.228
2.58
0.102
1.60
0.063
6.20
0.244
3.00
0.118
6.17
0.243
mm
inches
SCALE 3:1
*For additional information on our Pb?Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
SOLDERING FOOTPRINT*
H
0.370 0.410 9.40 10.41
A1
0.000 0.005 0.00 0.13
L1
0.108 REF 2.74 REF
L2
0.020 BSC 0.51 BSC
A1
H
DETAIL A
C
SEATINGPLANE
A
B
L1
L
H
L2
GAUGEPLANE
DETAIL A
ROTATED 90 CW
